Product Facility	Switzerland
Manufacturer	Refco Manufacturing Ltd.
Model	REFMATE-2-CA-WTC-V
Item Number	4688128
Number of Ways	2 - way
Pressure Range	-0.95 - 60 bar
Accuracy Class	0.5 (+/-0.5 %)
Pressure Scale	MPa \| bar \| kPa \| kg/cm2 \| psi
Resolution	0.001 bar, 0.5 psi, 0.0001 MPa, 0.01 kg/cm2, 1 kPa
Temperature Measuring Range	-40 - +125°C
Temperature Accuracy	+/-1 K
Temperature Units	°C \| °F
Temperature Resolution	0.1 °C / 0.1 °F
Sensor Type	K-type \| Pirani Sensor \| Piezo Sensor
Refrigerant(s)	R11 \| R113 \| R114 \| R12 \| R123 \| R124 \| R13 \| R13B1 \| R134a \| R14 \| R22 \| R23 \| R32 \| R41 \| R125 \| R142b \| R152A \| R161 \| R170 \| R227ea \| R236ea \| R236fa \| R245fa \| R290 \| R401A \| R401B \| R401C \| R402A \| R402B \| R403B \| R404A \| R406A \| R407A \| R407B \| R407C \| R407D \| R407F \| R407H \| R408A \| R409A \| R410A \| R412A \| R413A \| R414B \| R416A \| R417A \| R420A \| R421A \| R422A \| R422B \| R422C \| R422D \| R424A \| R426A \| R427A \| R434A \| R437A \| R438A \| R442A \| R444A \| R445A \| R448A \| R449A \| R450A \| R452A \| R452B \| R453A \| R454A \| R454B \| R454C \| R455A \| R470A \| R470B \| R500 \| R502 \| R503 \| R507 \| R507A \| R508A \| R508B \| R513A \| R600 \| R600a \| R744 \| R1270 \| R1234yf \| R1233zd \| R1234ze \| R411A
Operating Temperature Range	-20 - 50°C
Storage Temperature Range	-20 - 60°C
Battery	4 x AA \| 3x3AAA
Ingression Protection	IP42
Operating Hours	50 h at low operation
Gas Connection	1/4" SAE
Functions	Superheat / Subcool Digital / analogue display Slave pointer Pressure zeroing Data logging Tube error compensation Refrigerant favorites Refrigerant update Firmware update Set pressure reference Field calibration Unit and language settings Display brightness Wireless connections Commissioning date Printscreens
Signal Range	100 m
Number of Hoses	5
Length	60 ″
Working Pressure	60 bar
Burst Pressure	300 bar
Device Connection	1/4" SAE
System Connection	1/4" SAE \| 5/16" SAE or 1/2"-20 UNF \| With Core Depressor
Ball Valve	Evet
Sealing	PTFE
Scope of Supply	Batteries \| Case \| Instruction manual \| 5 Charging hoses with CA valve \| 2 wireless temperature clamps \| 2 wired temperature sensors \| Digital vacuum gauge
Material	Aluminium \| Brass \| ABS \| TPE
Standards	CE / FCC / IC / RCM / RoHS / REACH
RoHS Conformity	Yes
Net Weight [kg]	1.05
