Product Facility	Switzerland
Manufacturer	Refco Manufacturing Ltd.
Model	REFMATE-4-CA-TC
Item Number	4688126
Number of Ways	2 - way
Pressure Range	-0.95 - 60 bar
Accuracy Class	0.5 (+/-0.5 %)
Pressure Scale	bar \| psi \| kPa \| MPa \| kg/cm2
Resolution	0.001 bar, 0.5 psi, 1 kPa, 0.0001 MPa, 0.01 kg/cm2
Temperature Measuring Range	-40 - +125°C
Temperature Accuracy	+/-1 K
Temperature Units	°C \| °F
Temperature Resolution	0.1 °C / 0.1 °F
Sensor Type	K-type \| Piezo Sensor
Refrigerant(s)	R11 \| R12 \| R13 \| R13B1 \| R14 \| R22 \| R23 \| R32 \| R41 \| R113 \| R114 \| R123 \| R124 \| R125 \| R134a \| R142b \| R152A \| R161 \| R170 \| R227ea \| R236ea \| R236fa \| R245fa \| R290 \| R401A \| R401B \| R401C \| R402A \| R402B \| R403B \| R404A \| R406A \| R407A \| R407B \| R407C \| R407D \| R407F \| R407H \| R408A \| R409A \| R410A \| R411A \| R412A \| R413A \| R414B \| R416A \| R417A \| R420A \| R421A \| R422A \| R422B \| R422C \| R422D \| R424A \| R426A \| R427A \| R434A \| R437A \| R438A \| R442A \| R444A \| R445A \| R448A \| R449A \| R450A \| R452A \| R452B \| R453A \| R454A \| R454B \| R454C \| R455A \| R470A \| R470B \| R500 \| R502 \| R503 \| R507 \| R507A \| R508A \| R508B \| R513A \| R600 \| R600a \| R744 \| R1234yf \| R1233zd \| R1234ze \| R1270
Operating Temperature Range	-20 - 50°C
Storage Temperature Range	-20 - 60°C
Battery	4 x AA \| Alternative Power Supply USB Mirco-B
Ingression Protection	IP42
Operating Hours	50 h at low operation
Gas Connection	1/4" SAE
Functions	Superheat / Subcool, Digital / analogue display, Slave pointer, Pressure zeroing, Data logging, Tube error compensation, Refrigerant favorites Refrigerant update, Firmware update, Set pressure reference, Field calibration, Unit and language settings, Display brightness, Wireless connections, Commissioning date, Printscreens
Signal Range	100 m
Number of Hoses	5
Device Connection	1/4" SAE
System Connection	1/4" SAE \| 5/16" SAE or 1/2"-20 UNF \| 3/8" SAE \| With core depressor
Ball Valve	Yes
Sealing	PTFE
Scope of Supply	Piller \| Kasa \| CA valfli 5 şarj hortumu
Material	Aluminium \| Brass \| ABS \| TPE
Standards	CE / FCC / IC / RCM / RoHS / REACH
RoHS Conformity	Yes
Net Weight [kg]	1.05
Apple App
Google Play App
